HDU60 Horizontal Machining Center
HDU60 is a horizontal machining center for multi-face milling, boring, drilling, reaming and tapping in one setup.
Product Overview
HDU60 is a horizontal machining center for multi-face milling, boring, drilling, reaming and tapping in one setup.
Technical Specifications
| Capacity & workpiece | |
|---|---|
| Worktable size (L × W) | 600 × 600 mm |
| Maximum table load | 650 kg |
| Workpiece Range | Φ750 × 700 mm |
| Travel & guideways | |
| X/Y/Z axis travel | 1050 / 900 / 900 mm |
| Spindle | |
| Maximum spindle speed | 8,000 r / min Opt:12000 / 6000 |
| Spindle motor power | 31.5 kW |
| Spindle taper | No.50 (7:24) |
| Tooling | |
| Tool magazine capacity | 40 |
Application Industries
- Multi-face milling, boring, drilling, reaming and tapping in one setup.
