CT40 Slant Bed CNC Lathe

CT40 is a slant bed CNC lathe for production turning of shaft and disc-type workpieces.

Maximum swing diameter over bed
Φ500 mm
Maximum turning length
450 mm (A2-6) / 430 mm (optional A2-8 spindle)
Spindle speed range
45–4,500 r/min (A2-6) / 35–3,500 r/min (optional A2-8 spindle)
Guideway type
Linear guideway
CT40 machine view

Technical Specifications

SpecificationValue
Capacity & workpiece
Maximum swing diameter over bedΦ500 mm
Maximum turning length450 mm (A2-6) / 430 mm (optional A2-8 spindle)
Chuck size8″ (A2-6) / 10″ (optional A2-8 spindle)
Travel & guideways
Guideway typeLinear guideway
Maximum travel of X/Z axisX 165 mm / Z 500 mm
Maximum travel of tailstock460 mm
Spindle
Spindle speed range45–4,500 r/min (A2-6) / 35–3,500 r/min (optional A2-8 spindle)
Spindle motor power11 / 15 kW (FANUC)

Equipment configuration

Standard Configuration

  • FANUC CNC system
  • Hydraulic 8-position turret
  • A2-6 spindle nose
  • 8″ 3-jaw hydraulic chuck
  • THK ball screws and linear guideways
  • CE electrical components
  • Hydraulic tailstock
  • Chain-type chip conveyor and chip cart
  • Work light
  • Lubrication system
  • Heat exchanger
  • Hydraulic power unit
  • Alarm light
  • Toolbox
  • Steel pallet packaging
  • FANUC manual and PLC USB drive
  • Quality certificate and packing list
  • Electrical and mechanical operating manual
  • Safety interlocks
  • 45° slant guideways

Optional Configuration

  • Siemens 828D CNC system
  • GSK 988TD CNC system
  • HNC 808DI CNC system
  • A2-8 spindle with 10″ hydraulic chuck
  • Hydraulic 12-position turret
  • Turret accessories
  • Bar feeder
  • Hard or soft chuck jaws
  • Tool setter
  • Air conditioner
  • Wooden crate packaging
  • Oil mist separator
  • Oil-water separator
  • Parts catcher

Application Industries

  • Production turning of shaft and disc-type workpieces.
